Running the Pipeline

This pipeline converts dietary data (e.g., FFQs) and microbial gene information into a graph structure for analyzing metabolic interactions between food and gut microbes.

---

Overview

graph LR
  A[FFQ / Food List] --> B[Compound Source]
  B --> C[FooDB Workflow: DM and DMH]
  C --> D[Graph Data]
  D --> E[Pattern Extraction]
  E --> F1[Visualization]
  E --> F2[Metabolome]

Step	Description	Required
1	Launch Streamlit app to create machine-readable FFQ	Optional
2	Choose compound source (FooDB or KEGG)	✅
2A	If FooDB, determine if host is included	Optional
3A/3B	Generate nodes and edges	✅
4	Microbial compound report	Optional
5	Build graph and extract patterns	✅
6	Visualize results	Optional
7	Metabolome comparison	Optional

---

Step 1 — Create a Machine-Readable FFQ

Food Frequency Questionnaires (FFQs) capture how often participants consume specific foods, but they aren't directly usable in computational workflows due to format heterogeneity, lack of molecular resolution, and inconsistent structure.

A Streamlit app is provided to generate standardized, machine-readable FFQ datasets that map food items to compounds via FooDB.

streamlit run src/get_foods.py

In the app: 1. Search for and select foods 2. Assign a consumption frequency (1–100%) 3. Download the generated dataset 4. Shut down the application

No FFQ? No problem.

You can run the pipeline using all foods available in FooDB. Skip food metadata creation in Step 3, or pass the foodb and all-foods flags in the workflow runner. Food compound reports are skipped due to dataset size.

---

Step 2 — Choose a Compound Source

FooDB contains compounds identified in foods via LC-MS experiments, many of which link to KEGG. Core metabolic compounds (amino acids, sugars, fatty acids, nucleotides) are well-represented, but specialized plant compounds (flavonoids, alkaloids, terpenes) may be missing.

Limitations: Incomplete compound coverage · Limited food representation · U.S.-centric food data

Note

AMON takes a list of KOs and finds producible compounds via KEGG reactions, assigning their origin (host vs. microbial).

---

Step 3 — FooDB Workflow

1. Generate Food–Compound Metadata

Skip this step if using all FooDB foods — Data/AllFood/food_meta.csv is pre-built.

Rscript src/dietmicrobe/comp_FoodDB.R \
  --diet_file  "Data/test_sample/foodb_foods_dataframe.csv" \
  --content_file "Data/Content.csv" \
  --ExDes_file "Data/CompoundExternalDescriptor.csv" \
  --meta_o_file "food_meta.csv"

Output: Food items mapped to KEGG compound IDs with aggregated consumption frequencies.

2. Generate Food Compound Report (optional)

Skip if using all foods — the dataset is too large.

python src/dietmicrobe/RenderCompoundAnalysis.py \
  --food_file "food_meta.csv" \
  --output "food_compound_report.html"

3. Run AMON

amon.py \
  -i "Data/test_sample/noquote_ko.txt" \
  -o "AMON_output/" \
  --save_entries

4. Create Graph Data

python src/dietmicrobe/main_metab.py \
  --f "food_meta.csv" \
  --r "AMON_output/rn_dict.json" \
  --m_meta "Data/test_sample/ko_taxonomy_abundance.csv" \
  --e-weights \
  --n-weights \
  --org \
  --a "Abundance_RPKs" \
  --o "graph/"

---

Step 4 — Microbial Compound Report (optional)

Requires microbial taxonomy and abundance data.

python src/RenderCompoundAnalysis_Microbe.py \
  --node_file "graph/nodes.csv" \
  --edge_file "graph/edges.csv" \
  --output "microbe_compound_report.html"

---

Step 5 — Build Graph and Extract Patterns

For Diet -> Microbe patterns run:

python src/dietmicrobe/run_graph.py \
  --n "graph/nodes.csv" \
  --e "graph/edges.csv" \
  --o "graph_results.csv"

Patterns identified:

Pattern	Description
Food → Microbe	Compound produced by diet, consumed by microbe
Food → Both	Compound shared between diet and microbial production
Both → Both	Compound produced and consumed across both sources

For Diet -> Microbe -> Host patterns run:

python src/dietmicrobehost/host_run_graph.py \
  --n "graph/nodes.csv" \
  --e "graph/edges.csv" \
  --o "graph_results.csv"

Patterns identified

#	Pattern	Description
1	diet → microbe → host	Diet-only → microbial-only → host-only transformation
2	diet → microbe → hostdiet	Diet-only → microbial-only → host or diet origin
3	diet → microbe → hostmicrobe	Diet-only → microbial-only → host or microbial origin
4	diet → microbe → all	Diet-only → microbial-only → any source
5	diet → microbediet → host	Diet-only → diet or microbial → host-only
6	diet → microbediet → hostdiet	Diet-only → diet or microbial → host or diet origin
7	diet → microbediet → hostmicrobe	Diet-only → diet or microbial → host or microbial origin
8	diet → microbediet → all	Diet-only → diet or microbial → any source
9	diet → all → host	Diet-only → any source → host-only
10	diet → all → hostdiet	Diet-only → any source → host or diet origin
11	diet → all → hostmicrobe	Diet-only → any source → host or microbial origin
12	diet → all → all	Diet-only → any source → any source
13	microbediet → microbe → host	Diet or microbial → microbial-only → host-only
14	microbediet → microbe → hostdiet	Diet or microbial → microbial-only → host or diet origin
15	microbediet → microbe → hostmicrobe	Diet or microbial → microbial-only → host or microbial origin
16	microbediet → microbe → all	Diet or microbial → microbial-only → any source
17	microbediet → microbediet → host	Diet or microbial → diet or microbial → host-only
18	microbediet → microbediet → hostdiet	Diet or microbial → diet or microbial → host or diet origin
19	microbediet → microbediet → hostmicrobe	Diet or microbial → diet or microbial → host or microbial origin
20	microbediet → microbediet → all	Diet or microbial → diet or microbial → any source
21	microbediet → all → host	Diet or microbial → any source → host-only
22	microbediet → all → hostdiet	Diet or microbial → any source → host or diet origin
23	microbediet → all → hostmicrobe	Diet or microbial → any source → host or microbial origin
24	microbediet → all → all	Diet or microbial → any source → any source
25	all → microbe → host	Any source → microbial-only → host-only
26	all → microbe → hostdiet	Any source → microbial-only → host or diet origin
27	all → microbe → hostmicrobe	Any source → microbial-only → host or microbial origin
28	all → microbe → all	Any source → microbial-only → any source
29	all → microbediet → host	Any source → diet or microbial → host-only
30	all → microbediet → hostdiet	Any source → diet or microbial → host or diet origin
31	all → microbediet → hostmicrobe	Any source → diet or microbial → host or microbial origin
32	all → microbediet → all	Any source → diet or microbial → any source
33	all → all → host	Any source → any source → host-only
34	all → all → hostdiet	Any source → any source → host or diet origin
35	all → all → hostmicrobe	Any source → any source → host or microbial origin
36	all → all → all	Any source → any source → any source

---

Step 6 — Visualize Graph Results

python src/dietmicrobe/RenderGraphResults_Report.py \
  --patterns "graph_results.csv" \
  --rxn_json "AMON_output/rn_dict.json" \
  --output "graph_results_report.html"

or

python src/dietmicrobehost/RenderGraphResults_Report.py \
  --patterns "graph_results.csv" \
  --rxn_json "AMON_output/rn_dict.json" \
  --output "graph_results_report.html"

Step 7 — Metabolome Comparison

To view which compounds identified in the patterns were also found in a metabolomics experiment you performed, two inputs are needed:

Inputs

1. A graph_results.csv or the output of Step 4.

2. CSV containing a list of KEGG compounds that were identified in the metabolome. An example of this file can be found in Data/test_sample/metabolome.csv.

Running the script

To get a list of optional and required arguments run python src/RenderMetabolomeComparison.py -h:

options:
  -h, --help            show this help message and exit
  --patterns PATTERNS   Path to the graph_results.csv
  --metabolome METABOLOME
                        Path to CSV file containing one column of KEGG compounds.
  --output OUTPUT       Path to HTML report file

Tip

Use run_workflow.py to run steps 2-7 with Snakemake workflow described on the home page automatically. See the Quick Start guide for a complete example.
